产品简介
• 取样式气体探测报警系统是一种能进行多个采样点自动循环取样的系统。
• 气体探测器对所有采样点是通用的，允许使用各类型的气体探测器。
• 当某个采样点的气体成分达到设定的报警浓度时，气体探测器输出信号，显示面板显示相应的报警信息，发出声光报警信号 .
• 系统对每个点的采样时间可根据每个采样点的管道长度单独调整，这提供了最佳的短循环时间。
• 一个循环时间不超过 30 分钟。
• 系统具有历史记录功能。
Product Introduction
• The aspirating gas detection and alarm system performs automatic cyclic sequential sampling from multiple sampling points.• The gas detector is universal for all sampling points and compatible with all types of gas sensors.• When the gas concentration at any sampling point reaches the preset alarm threshold, the gas detector transmits signals. The display panel will show corresponding alarm messages and trigger audible & visual alarms simultaneously.• The sampling duration for each point can be adjusted independently according to the pipeline length of each sampling point, which optimizes the minimum cycle time.• One full sampling cycle shall not exceed 30 minutes.• The system supports historical event logging function.
产品组成
• 0" 彩色触摸屏
• 可编程继电器输出
• 可编程继电器输入
• 4-20mA 输入（用于连接气体探测器）
• 通信输出（RS485:NMEA0183、MODBUS RTU）
System Composition
• 10-inch color touch screen (Original "0"" is a typo)• Programmable relay outputs• Programmable relay inputs• 4–20 mA analog inputs (for connecting gas detectors)
• Communication outputs (RS485: NMEA 0183, Modbus RTU)
应用场景
• 海洋石油平台
• 运油船 / 化学品船
• 船用供气系统
• 危险品储存
• FPSO
• FLNG
Application Scenarios
• Offshore oil platforms• Oil tankers / Chemical tankers• Marine gas supply systems• Hazardous goods storage areas• FPSO (Floating Production Storage and Offloading units)• FLNG (Floating Liquefied Natural Gas units)
